M8P
$49.99
500W | 20A | 8S
Input Voltage: DC 7-35V@MAX25A
Battery Type: LiPo LiHV LiFe Lilon LTO@1-8S, NiMH@1-20SPb@1-10S
Charge Power: 0.1-20A@600W
Discharge Power: 0.1-20A@600W / Recycle external 0.1-
3A@20W
Measure:PWM/PPM /SBUS /Voltage /Internal resistance /ESC
Output:PWM /PPM /SBUS /Power supply
Product size: 99*72*35mm
Product wight: 180g
Free shipping on orders over $5.98!
- No-Risk Money Back Guarantee!
- No Hassle Refunds
- Secure Payments
- For US regions, please check the shipping on the checkout page
SPEC
GENERAL
| Product size | 99×72×35mm |
| Product weight | 180g |
| Packing size | 125×81×41mm |
| Packaging weight | 250g |
| LCD | IPS 2.4″ LCD 320×240px |
CHARGER
| Input voltage |
7.0-35.0V @MAX 25A |
| Battery type |
LiPo LiHV LiFe Lilon LTO@1-8S NiMH @1-20S Pb @1-12S |
| Balance current |
1000mA @ 4.2V |
| Charging power |
600W @MAX 20A |
| Discharging power |
600W @MAX 20A Recycle mode 20W@3A Normal mode |
| USB |
2.1A@5.0V or Upgrade |
MEASURER
| PWM |
880-2200us @ 20-400Hz |
| PPM |
880-2200us×8CH @ 20-50Hz |
| SBUS |
880-2200us×16CH @ 20-100Hz |
| Voltage |
1.0-5.0V @ 1-8S |
| Internal resistance |
0.1 mR-99R @ 1-8S |
| ESC |
600W @ 20A |
OUTPUT
| PWM |
500-2500us @ 20-1000Hz |
| PPM |
880-2200us×8CH @ 20-50Hz |
| SBUS |
880-2200us×16CH @ 20-100Hz |
| Power supply |
1.0-35.0V @1.0-20A mode:CC CV |
| Overcurrent response |
<5ms |
IN THE BOX
M8AC Charger × 1, AC Input Cable × 1, USB Cable × 1, Quick Manual × 1, Screen Protector × 1
