ToolkitRC

POWERFUL DUAL OUTPUT, WITH

SMART POWER DISTRIBUTION.

The charging power is dynamically and intelligently distributed in the circumstance.

Whenever one or dual port working, The full power is always used efficiently!

MULTIPLE UNITS WORKING TOGETHER,

MAKING CHARGING SMARTER



Set any unit as the master to quickly and easily synchronize its charging settings to

multiple slave units for precise overall control.

SUPPORT DRONECAN SMART BATTERY

COMMUNICATION



Simply connect the smart battery to the charger, and it will automatically retrieve

battery information for charging without any setup.

THE ALL-NEW UI WITH

SMART 3.5″ IPS LCD DISPLAY



A simple, large-color interface provides easy access to key data.Quickly access detailed real-time battery data by clicking on a page.

KEEP YOU FULLY CHARGED AT ANY TIME

Powerup most contemporary mobile devices-your smartphones, tablets ,laptops and remote control ect.

EXTREMELY COMPACT SIZE,

WITH CARRYING

HANDLE

DYNAMIC

LIGHT STRIP

REAL-TIME INDICATION

OF CHARGING STATUS

COMPREHENSIVE SECURITY PROTECTION

IN THE BOX

AC INPUT CABLE OPTIONS
US
EU
UK
AU

SPEC

General

Product size

314.7×153.9×145.6mm

Product weight

3100g

Pack size

344.7×184×198mm

Pack weight

3850g

LCD

3.5″ IPS RGB 480×320px

Charger

Input voltage

AC 220.0-240.0V@MAX 2600W

AC 100.0-120.0V@MAX 1300W

Type of battery

LiPo LiHV@6-14S

Charging power

1.0-30.0A@1250W×2 AC 220V

1.0-30.0A@600W×2 AC 110V

1.0-50.0A@2500W SYNC AC 220V

1.0-50.0A@1200W SYNC AC 110V

Discharging power

1.0-5.0A@60W×2

Balance current

MAX2000mA@2-14S

TypeC output

MAX 65W@MAX 20V

Internal resistance

1mΩ-9.9Ω@6-14S

Operating

2 sets of buttons

Output connector

2×AS150U male port

1×Type C
