HIGHLY INTEGRATED, LIGHTER, SMALLER AND SIMPLER
Upgrade based on M8P, internal power supply added, make charging easier
1000MA ROBUST BALANCE CURRENT
& HIGH BALANCE ACCURACY <0.005V
Experience 2-3 times faster and more efficient battery balancing, achieving
excellent peak performance for your battery.
Powerup most contemporary mobile devices-your smartphones, tablets and laptops.
NOT ONLY A CHARGER, BUT ALSO…
SMART 2.4″ IPS LCD DISPLAY
Always clearly display the real-time charging status in any light environment or under any angle
COMPREHENSIVE SECURITY PROTECTION
IN THE BOX
M8AC Charger × 1, AC Input Cable × 1, USB Cable × 1, Quick Manual × 1, Screen Protector × 1
SPEC
CHARGE
Input voltage
AC 100-240V@MAX2.5A
DC 7-35V@MAX25A
Battery type
LiPo LiHV LiFe Lilon LTO @1-8S
NiMH@1-20S Pb@1-12S
Balance current
1000mA@4.2V
Balance accuracy
<0.005V
Charging power
0.1-20A@600W
Discharging power
0.1-20A@600W Recyle mode
0.1-3A@20W Normal mode
USBC output
MAX 20.0V@65W Upgrade
Voltage
1.0V-5.0V@1-8S
Internal resistance
1-99mΩ@1-8S
MEASURER
PWM
880us-2200us@20-400Hz
PPM
880us-2200us×8 CH@20-50Hz
SBUS
880us-2200us×16 CH@20-100Hz
OUTPUT
PWM
500us-2500us@20-1000Hz
PPM
880us-2200us×8CH@50Hz
SBUS
880us-2200us×16CH@74Hz
Power supply
1-20A@1-35V Mode: CC+CV
GENERAL
Product size
108×113×62mm
Product weight
500g
Packing size
136×153×67mm
Packaging weight
600g
LCD
IPS 2.4″ LCD 320×240px
